- Product Name:8dBi UHF RFID Filing Cabinet Antenna/PCB RFID Antenna 860-96
- Product Model:NR-A190
Cantact Us:
- Product Overview
8dBi UHF RFID Filing Cabinet Antenna/PCB RFID Antenna 860-960Mhz
| Electrical Specifications | |
| Frequency | EU frequency 865-868Mhz or US :902-928Mhz |
| Gain | 8dBi |
| Beam width | Hor:75° Ver:75° |
| Polarization | Circular |
| VSWR | ≤1.4 |
| F/B Ratio | ≥20 |
| Impedance | 50Ω |
| Maximum power | 50W |
| Lightning protection | DC Ground |
| Connector | SMA-Female |
| Mechanical Specifications | |
| Dimension | 190*190*20mm |
| Net weight | 0.15kg |
| Packing size | 21*4*21cm |
| Gross weight | 0.22kg |
| Radome material | PCB |
| Radome colour | Yellow |
| Operating temperature | -40-70℃ |
