Technical Parameter Frequency 902MHz ~ 928MHz or 866-868Mhz Gain 12dBi Bandwidth 26MHz V.S.W.R 1.2 Half-Power Angle 40 Maximum Power 100W Resistance 50 Polarization Mode Linear Polarization Connector N type Female connector Lightning Protec

Name: long plate antenna Application: ★ 902-928MHz RFID radio frequency identification system. ★ European standard can be customized (860-868MHZ) ★ Management of filing cabinets and filing cabinets ★ Access control channel, storage

Name: RFID antenna Application: ★ 902-928MHz RFID radio frequency identification system. ★ European standard 860-868MHz can be customized. ★ Event identification, marathon, bicycle race system. ★ Access control channel management. ★

Technical Parameter Frequency 902MHz~928MHz or 866-868Mhz Gain 9dBi Bandwidth 26MHz V.S.W.R 1.1 Half-Power Angle 60 Maximum Power 100W Resistance 50 Polarization Mode Circular Polarization Connector SMA Female connector Lightning Protection

Electrical Specifications Frequency 860-960MHz Gain 8dBi Beam width Hor:75 Ver:75 Polarization Circular VSWR 1.4 F/B Ratio 20 Impedance 50 Maximum power 50W Lightning protection DC Ground Connector SMA-Female Mechanical Specifications Dimen

8dBi UHF RFID Filing Cabinet Antenna/PCB RFID Antenna 860-960Mhz

Technical Parameter Frequency 902MHz~928MHz or 866-868Mhz Gain 9dBi Bandwidth 26MHz V.S.W.R 1.1 Half-Power Angle 60 Maximum Power 100W Resistance 50 Polarization Mode Circular Polarization Connector SMA male connector Lightning Protection G

Technical Parameter Frequency 902MHz~928MHz or 866-868Mhz Gain 15dBi Front-to-Rear Ratio ＞25dB V.S.W.R 1.4 Half-Power Angle 232 E angle 75H angle Maximum Power 100W Resistance 50 Third Order Intermodulation -107dBm Polarization Mode Horiz
